Metal cutting of Ti6Al4V alloy
-
Numerical modeling [in]
-
Material law: ​Johnson-Cook model
-
Material failure: bond-failure model
-
Numerical method: Smoothed Particle Galerkin​ (SPG)
-
The shear band with regular pattern is accurately captured by numerical simulation. The convergence study shows improving agreement with experiment.
The animation of numerical result below shows the detail of cutting process. This powerful numerical tool has been successfully applied to metal shearing and bushing analysis.
Sheet Metal Punching
-
Experiment data is available [Svanberg, 2019]
-
Numerical modeling
-
Material law: MAT_PIECEWISE_LINEAR_PLASTICITY
-
Material failure: bond-failure with maximum shear strain (IDAM=3, FS=2.2)
-
Numerical method: Smoothed Particle Galerkin​ (SPG)
-
-
Comparison: FEM with element erosion + GISSMO model
1/8 model
EPS
Max Principle Strain
